Cross GRX 7 VBR 29"
Cross GRX mountain bike
The model will also be available in a GRX 7 VBR version - again in 29" and 27.5" (in the photo and video), keeping the front fork and 21 speeds, but the transmission is now Shimano TOURNEY -RD-TY300 with ST commands -EF41. Frame heights 410 / 460 / 510mm. The brakes here are aluminum V-brake type, working on the double-walled aluminum profile of the CROSSER X2 rims. Both versions are budget HS hard drives intended for normal use.
Specification:
Frame |
Aluminum hardtail GRX DB - ALLOY 6061 with increased stiffness - tubes with round and oval section and reinforcing detail m/u front and bottom. For disc or (V-brake) type brake. Color - matte black, with stickers under powder coating, resistant to shocks and scratches. Heights: 460 / 510 / 560mm |
Fork |
SUNTOUR SF18-XCE28-P-29 Stroke 100mm. Aluminum body and crown, steel rod (1-1/8") and guides (Ø25.4mm). For (V-brake) type brake. Damper spring with stiffness adjustment. |
Fork cups |
VP-A42E, semi-integrated 1.1/8” |
Fork spacers |
HL SPR02, aluminum washers (spacers) - matt black, 3 pieces of 10 mm. |
Rudder |
HL MTB-AL-320BT-FOV, ∅ 31.8 mm, length 680 mm, elevation 15 mm and back bending +6°. |
Paw |
HL TDS-C507-8FOV, aluminum (3D forged), with angle +7° and length 80mm, for handlebar Oversize (Ø31.8) and stemmed 1.1/8". |
Grips |
Velo, VLG-311AD2, – sports, black. |
Seat |
Golden Wheel GW-1168, sport-lightweight, Blue. |
Seat peg |
PROMAX SP-222, aluminum, black matt, ∅ 31.6mm, length 350 mm. |
Seat Bracket |
PROMAX MX27, ∅ 35 mm, aluminum, with lever for quick fixing. |
Speeds |
21 speed SHIMANO system |
Commands |
SHIMANO ASTEF41LBL + ASTEF41R7AL |
Courbeli |
SHIMANO AFCTY301C244XL, aluminum, with triple ring 42 / 34 / 24T, arm length 170 mm. |
Axis-Cassette |
SHIMANO ABBUN100B22B |
Front derailleur |
SHIMANO AFDTY500TSM6 |
Rear derailleur |
SHIMANO ARDTY300D |
Chain |
KMC Z7 1/2" x 3/32" link length 7.3mm |
Wreath Cassette |
SHIMANO ACSHG20I7232 |
Front hub |
JOY TECH JY751 QR 36H, aluminum, black. |
Rear hub |
OY TECH JY752 QR 36H, aluminum, black. |
Drops |
Double wall V-brake aluminum profile CROSSER X2, with 36 spoke holes and dimensions 584 x19mm, height 21mm, and black spokes 14G |
Pedals |
VP-536 |
Brakes |
PROMAX, TX115C, V-brake type, aluminum, black. |
Brake levers |
SHIMANO ASTEF41LBL + ASTEF41R7AL - integrated in the commands. |
Tires |
KENDA K1104A 29x2.10, 22TPI AV 35mm, black. |
The GRX VBR model is also based on the standard frame, but is equipped with the lowest specification for the season and will again be available in 2 versions of 29” and 27.5” wheels. The frame again has a classic HS geometry, keeping all the structural features that ensure the famous strength. Again, the same oval, aluminum tubes are used, which for the front triangle have intersecting elliptical sections - turned horizontally at the seat tube and smoothly flowing into vertical at the head tube. To counteract the bending in this area (when wading at high speed over bumps), the two pipes are again partially cut, and the characteristic additional strengthening element is preserved in the base between the front and the bottom. The rigidity of the frame under lateral load is also guaranteed by the characteristic layout in its upper part, where the corresponding tubes of the front and rear triangles are side by side, also wrapping laterally that for the seat. The seat, brakes and their controls, as well as the fork, are also black, blending into the overall tone, and the color accents in some of the components harmonize with the specific color scheme of the graphics, giving a simple look to the whole bike. The SUNTOUR-SF18-XCS fork itself has 100mm of travel and decent spring damping capacity, offering adjustable stiffness as well. The bike is equipped with 21 speeds and main components from the SHIMANO series, but here the brakes are of the (V-brake) type and work on suitable Crosser rims with X2 double-wall aluminum profile. They are fitted with balloon tires with a normal off-road tread, facilitating the passability of the mountain bike, which is solidly constructed and adequately equipped for its price class, on trails of a heterogeneous nature.
When you buy this bike, you get a voucher for 10% DISCOUNT for buying a second Cross bike, through our website www.velosiped.bg or in Cross company stores.
The voucher is valid for up to one year after the purchase of a bike and is valid for all bikes outside of current promotions!
Color | Grey |
---|
